U Shaped Drawers and Rollouts Package

U Shaped Drawers and Rollouts Package

Regular price $0.00 USD
Regular price Sale price $0.00 USD
Sale Sold out

This is a very simple and elegant solution to the u-shaped rollouts problem...and this is one is on us.  That's right it's FREE.

Overview -  This package has a small footprint.  It's consists of one UCS called "U Shaped  Drawers and Rollouts - CWES".  With the UCS enabled, a T/F attribute is created called "U-Shaped drw or rollout?"  which becomes visible when you click on a ROF (rollout front) part or DRW (drawer) part a from any orthographic view at the "cabinet level".

When the attribute is set to True, you can then control the width, depth and location left to right of the "cutout" of the drawer or rollout tray.

It's not tied to any particular construction methods for rollouts and, likewise, it's not restricted to any particular construction type.



WHAT'S INCLUDED

Included in the zip file is one UCS..."U Shaped Drawers and Rollouts - CWES"

View full details

FAQ's

Q: What versions of Cabinet Vision does this work with?
A: This has been tested on version 2023 build 4. However, it should work without any issues on Cabinet Vision 9 to newest versions including CV 2025.

Q: Does this work on drawers and rollout trays?
A: This UCS works as described with any drawer and any rollout. It "fires" by touching either a DRW or a ROF part.

Q: How do I install this UCS?
A: The download for this is a zip file. So, you'll have to first "Extract" the zip file. Here's a good video that can take this answer from there. https://craftsmanengineering.com/video/how-import-and-install-packages-cabinet-vision-beginner
